EFB Electronics I-V(ZN)H 2G50/125 OM3 Zipcord 2.8x5.7mm Aqua

The EFB Electronics I-V(ZN)H 2G50/125 OM3 Zipcord patch cable is a high-performance indoor fiber optic cable designed for reliable data transmission in demanding network environments. With its duplex 50/125 µm multimode fibers and OM3 classification, it supports high-speed applications up to 100 Gbps over short distances. The cable features a robust LSZH (Low Smoke Zero Halogen) jacket in aqua, ensuring safety and easy identification.

Advantages

This cable offers exceptional bandwidth and low attenuation, making it ideal for high-speed data centers and enterprise networks. The zipcord design allows for easy separation and termination, while the LSZH jacket provides enhanced fire safety and reduced toxic emissions. Its compliance with international standards ensures interoperability and reliability.

Suitable for

• Data center cabling
• Enterprise network backbones
• High-speed LAN applications
• 10/40/100 Gigabit Ethernet
• Storage area networks (SAN)

Key specifications

• Fiber Type: Multimode OM3
• Fiber Count: 2 (Duplex)
• Core/Cladding: 50/125 µm
• Cable Construction: Zipcord
• Jacket Material: LSZH
• Jacket Color: Aqua
• Outer Dimensions: 2.8 x 5.7 mm
• Attenuation @ 850nm: ≤ 2.5 dB/km
• Attenuation @ 1300nm: ≤ 0.8 dB/km
• Modal Bandwidth @ 850nm: 1500 MHz·km
• Effective Modal Bandwidth @ 850nm: 2000 MHz·km
• Max Data Rate: 10 Gbps up to 300m, 40 Gbps up to 100m, 100 Gbps up to 70m
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -20°C to +70°C
• Minimum Bending Radius (Installation): 57 mm
• Minimum Bending Radius (Operation): 28.5 mm
• Standards: ISO/IEC 11801, EN 50173-1, TIA/EIA-568-C.3, IEC 60794-2
• Fire Performance: IEC 60332-1-2, IEC 61034-2, IEC 60754-1/2

Recommendations

For optimal performance, use with OM3-compatible transceivers and connectors. Ensure proper cable management to maintain bend radius specifications. This cable is not suitable for outdoor or direct burial applications.
