EATON Μηχανισμός μπουτόν 16A/1 S Z-PU/S (276291)

Rated at 16 A and 250 V AC, this momentary push-button switch insert delivers reliable control for flush-mounted installations, compatible with Gira System 55 design lines.

Overview

The EATON 276291 is a 1-pole push-button switch insert with a single normally open (NO) contact. It is designed for flush mounting and features screw terminals for secure wiring. The insert is halogen-free and made of thermoplastic, with a white finish.

What stands out

• Momentary NO contact for push-button applications
• 16 A rated current, suitable for lighting and control circuits
• Flush-mounted design compatible with Gira System 55 frames
• Halogen-free thermoplastic construction
• Screw terminals accept solid conductors from 1.5 to 2.5 mm²

Technical details

• Switching function: Momentary (NO)
• Contact configuration: 1 NO
• Number of poles: 1
• Rated current: 16 A
• Rated voltage: 250 V AC
• Connection type: Screw terminals
• Mounting type: Flush-mounted
• Compatible system: Gira System 55
• Material: Thermoplastic
• Colour: White
• Halogen-free: Yes
• Terminal capacity (solid): 1.5 - 2.5 mm²

Our verdict

A straightforward, robust push-button insert for standard flush-mounted installations, offering compatibility with Gira System 55 and reliable 16 A switching.
