Eaton M22-E4 πλάκα τοποθέτησης για 4 χειριστήρια, ανθρακί 216545

Mounting multiple control devices in a panel can be time-consuming and error-prone. The Eaton M22-E4 mounting plate solves this by providing a pre-drilled, robust plate that holds four M22 series devices in a compact 2x2 arrangement, simplifying installation and ensuring a clean, professional layout.

Who is it for

Panel builders, electricians, and maintenance technicians who work with Eaton M22 control devices and need a reliable, front-mounting solution for control panels and enclosures.

Main features

• Holds up to 4 Eaton M22 control devices in a 2x2 grid
• Front mounting for easy access and installation
• Made from durable polycarbonate in anthracite colour
• 22.5 mm hole diameter matches M22 series components
• Compatible with Eaton M22 series pushbuttons, pilot lights, and selector switches

Specifications

• Accessory Type: Mounting Plate
• Compatibility: Eaton M22 Series Control Devices
• Number of Positions: 4
• Mounting Method: Front Mounting
• Material: Plastic (Polycarbonate)
• Colour: Anthracite
• Hole Diameter: 22.5 mm
• Operating Temperature: -25 to +70 °C
• Storage Temperature: -40 to +80 °C
• Series: M22
• Number of Rows: 2
• Number of Columns: 2

Tips

Ensure the mounting surface is clean and flat before installation. The plate is designed for front mounting; verify that your enclosure has adequate depth for the M22 devices and wiring.
