Eaton 271461 ακροδέκτης καλωδίου σωλήνα, χαλκός, ευθύς, 10 mm²

When joining solid or stranded copper conductors, a secure, low-resistance connection is essential to prevent overheating and voltage drop. The Eaton 271461 tubular crimp connector provides a reliable solution for 10 mm² copper conductors, ensuring a permanent, gas-tight joint through crimping.

Who is it for

This connector is intended for electricians, panel builders, and maintenance technicians who need to create durable electrical connections in distribution boards, control cabinets, or industrial wiring. It is suitable for use with copper conductors only.

Main features

• Made of electrolytic copper (E-Cu) for excellent conductivity and corrosion resistance.
• Straight, uninsulated design for use in protected environments or with additional insulation.
• Accepts 10 mm² conductors; crimp connection ensures mechanical strength and electrical integrity.
• Bare metallic surface, no plating, ideal for standard copper-to-copper joints.

Specifications

• Connector type: Tubular crimp connector
• Material: Electrolytic copper (E-Cu)
• Conductor cross-section: 10 mm²
• Design: Straight
• Connection method: Crimp
• Surface finish: Bare metallic
• Insulation: Uninsulated
• Outer diameter: 6.5 mm
• Inner diameter: 4.5 mm
• Overall length: 30 mm
• Conductor compatibility: Copper
• Colour: Copper (metallic)

Tips

Use a calibrated crimping tool with the correct die for 10 mm² to achieve a full-depth crimp. For installations where the connector may be exposed to moisture or accidental contact, apply heat-shrink tubing or insulating tape after crimping.
