DSIT Ελεγκτής οπτικών ινών SE-13013377

Fiber optic network issues can bring your entire operation to a halt, but pinpointing faults without the right tools is a frustrating guessing game. The DSIT SE-13013377 Fiber Optic Tester eliminates that uncertainty by combining an optical power meter, a stabilized light source, and a visual fault locator in one compact, field-ready unit. Whether you're certifying new installations, troubleshooting existing links, or performing routine maintenance, this tester gives you accurate, repeatable measurements across all common fiber types and wavelengths.

Who is it for

Network technicians, installers, and maintenance crews working with single-mode and multi-mode fiber will appreciate the SE-13013377's versatility. It's ideal for enterprise LAN/WAN environments, data centers, telecom outside plant, and FTTx deployments. Contractors who need to validate link loss, locate breaks, or verify continuity will find it indispensable for daily use.

Main features

• Integrated OPM, OLS, and VFL functions in one device
• OPM measures at 850, 1300, 1310, 1490, 1550, and 1625 nm with a range of -70 to +10 dBm
• High accuracy of ±0.2 dB ensures reliable loss measurements
• Stabilized laser source at 1310/1550 nm with -5 dBm output and ±0.05 dB stability
• Visual fault locator emits 650 nm red light at 10 mW to trace fibers and find breaks
• Universal 2.5 mm and 1.25 mm adapters support FC, SC, ST, and LC connectors
• Monochrome LCD with backlight for clear readings in any environment
• Stores up to 1000 test results and transfers data via USB
• Powered by 3 AA batteries or AC adapter, with up to 100 hours battery life

Specifications

• Product Type: Fiber Optic Tester (OPM, OLS, VFL)
• OPM Wavelengths: 850, 1300, 1310, 1490, 1550, 1625 nm
• OPM Measurement Range: -70 to +10 dBm
• OPM Accuracy: ±0.2 dB
• OLS Wavelengths: 1310, 1550 nm
• OLS Output Power: -5 dBm
• OLS Output Stability: ±0.05 dB
• VFL Wavelength: 650 nm
• VFL Output Power: 10 mW
• Connector Type: Universal 2.5mm (FC/SC/ST), Universal 1.25mm (LC) with adapters
• Fiber Compatibility: Single-mode (SM) and Multi-mode (MM)
• Display: Monochrome LCD with Backlight
• Power Source: 3 x AA Batteries or AC Adapter
• Battery Life: Up to 100 hours (OPM only)
• Auto-Off Function: Yes, configurable
• Data Storage: Up to 1000 test results
• PC Connectivity: USB for data transfer
• Operating Temperature: -10°C to 50°C
• Storage Temperature: -20°C to 70°C

Tips

Always clean connectors before testing to avoid inaccurate readings. For VFL use, avoid looking directly into the fiber end. Store the unit in a dry, cool place when not in use, and remove batteries if storing for extended periods.
