DSIT DC-Wall-Frame-W πλαίσιο τοίχου Keystone 2 θυρών, λευκό

Exposed network outlets can ruin the clean look of any room and leave connections vulnerable to dust and damage. The DSIT DC-Wall-Frame-W solves this by providing a sleek, white wall frame that neatly houses standard keystone jacks, turning untidy cable ends into a professional flush-mounted data point.

Who is it for

This frame is ideal for electricians, network installers, and homeowners who need a reliable and attractive solution for terminating Ethernet, telephone, or multimedia cables in residential or commercial spaces. It is perfect for new installations or retrofitting existing flush-mount boxes.

Main features

• Compatible with standard keystone jacks (19.2 x 14.9 mm opening) for versatile module choices.
• 2-port capacity allows two connections in a single gang footprint.
• Flush mount design with hidden screws for a clean, professional appearance.
• Made from durable ABS plastic with a matte white finish (RAL 9010 equivalent).
• Removable cover plate simplifies module installation and future changes.
• UV-resistant and fire-retardant (UL94 V-0) for long-lasting safety.

Specifications

• Product type: Wall frame for data outlets
• Colour: White
• Material: ABS plastic
• Module capacity: 2-port
• Module compatibility: Standard keystone jack (19.2 x 14.9 mm opening)
• Mounting type: Flush mount
• Installation method: Screw-on (with hidden screws)
• Design: Single gang (standard European size)
• Application: Data network, telecommunications, multimedia
• Finish: Matte
• UV resistance: Yes
• Fire retardancy: UL94 V-0
• Operating temperature: -10°C to +60°C
• Certifications: RoHS compliant
• Included components: Frame, cover plate, mounting screws
• Compatibility: Suitable for standard 60mm flush-mount boxes
• Dimensions (W x H): 80 x 80 mm
• Depth (from wall): 12 mm

Tips

For a seamless look, pair this frame with white keystone jacks and matching faceplates. When installing, ensure the flush-mount box is securely fixed and the wall surface is clean for a tight fit. The removable cover allows easy access for future upgrades or maintenance.
