Δίσκος δίσκου πλάκα κάλυψης Synology D8 2,5/3,5 ίντσες μαύρο

The Synology DISK TRAY (TYPE D8) is a bezel panel compatible with both 2.5" and 3.5" drives, finished in black for a discreet appearance. It measures 172 mm (W) x 118 mm (D) x 28 mm (H) and is intended to simplify drive installation and secure mounting within a 4-bay enclosure that uses the 18~ series tray form factor.

Advantages

The tray provides a universal mounting solution for 2.5" and 3.5" hard drives and SSDs, offering tool-less snap-in or screw-secure installation depending on your enclosure. Its black bezel improves the visual uniformity of multi-bay storage units while maintaining a compact profile. Designed by Synology, the tray is built to fit compatible systems and to facilitate easy drive replacement or expansion.

Suitable for

• Replacing or expanding drive bays in Synology-compatible 4-bay enclosures (18~ series)
• Mounting 2.5" SSDs or 3.5" HDDs in a single bezel panel
• Maintaining neat front-panel appearance in small NAS or storage chassis

Key specifications

• Brand: SYNOLOGY
• Model / MPN: DISK TRAY (TYPE D8)
• Compatibility: 2.5" and 3.5" drives
• Dimensions: 172 mm (W) x 118 mm (D) x 28 mm (H)
• Color: Black
• EAN: 4711174729982

How to use

Insert the drive into the tray following the orientation marks on the bezel, then secure it according to your enclosure's method—either by snapping into place or fastening with screws where applicable. Slide the assembled tray into the corresponding bay until it locks. For removal, release the bay latch or unlock the tray, then pull the bezel outward while supporting the drive to avoid damage.

Recommendations

Use compatible Synology or 18~ series enclosures and follow the enclosure manufacturer’s instructions for drive installation. Handle drives on an anti-static surface and ensure the system is powered down before inserting or removing trays to prevent data loss or hardware damage.
