DIGITUS Unmanaged Switch PoE - 24 θυρών Gigabit + 2 θυρών Gigabit SFP

DIGITUS Unmanaged Switch PoE - 24 θυρών Gigabit + 2 θυρών Gigabit SFP
DIGITUS Unmanaged Switch PoE - 24 θυρών Gigabit + 2 θυρών Gigabit SFP
DIGITUS Unmanaged Switch PoE - 24 θυρών Gigabit + 2 θυρών Gigabit SFP
DIGITUS Unmanaged Switch PoE - 24 θυρών Gigabit + 2 θυρών Gigabit SFP
DIGITUS Unmanaged Switch PoE - 24 θυρών Gigabit + 2 θυρών Gigabit SFP
DIGITUS Unmanaged Switch PoE - 24 θυρών Gigabit + 2 θυρών Gigabit SFP
367,16 €
Wire-speed forwarding, intelligent identification, PoE output power of a single port supports up to 30W each, total PoE budget: 370W- Support IEEE802.3af/at Standard- Single port output power up to 30W- Automatic detection and identification of standard PoE power receiving devices, intelligent power... Περισσότερα
Απόθεμα 14 Κωδικός 116844 Μάρκα DIGITUS Μοντέλο DN-95348-2 Εγγύηση 2 χρόνια

Αποστολή & επιστροφές

Εκτιμώμενη παράδοση Τετάρτη, Οκτωβρίου 28
Θα ενημερώνεστε μέσω του αναλυτικού μας συστήματος παρακολούθησης
Τρόποι πληρωμής
Τραπεζική κάρταVisaMastercardPayPalApple PayGoogle PayΤραπεζική κατάθεση

Wire-speed forwarding, intelligent identification, PoE output power of a single port supports up to 30W each, total PoE budget: 370W

- Support IEEE802.3af/at Standard
- Single port output power up to 30W
- Automatic detection and identification of standard PoE power receiving devices, intelligent power supply, will not burn non-standard PoE power receiving devices or common devices
- Support port power supply prioritization, guarantee the continuous power supply of key nodes
- Panel indicators monitor working status and help fault analysis
- Support VLAN and CCTV function
- Flow Control for Full Duplex operation and back pressure for Half Duplex Operation
- Support Energy-Efficient Ethernet (EEE) function (IEEE802.3az)

The DN-95348-2 PoE switch offers an outstanding solution for the efficient power supply of network components that support the IEEE802.3af/at standard. With an impressive single port output power of up to 30W, it enables the reliable supply of PoE-enabled devices. The automatic detection and identification of standard PoE receiving devices makes the power supply intelligent and prevents potential damage from non-standard or conventional devices. By prioritising the port power supply, the module ensures the module ensures a continuous power supply for critical network nodes. The panel indicators allow convenient monitoring of the working status and assist in fault analysis. The module also supports VLAN and CCTV functions to maximise flexibility in network applications. With flow control for full-duplex operation and back pressure for half-duplex operation, the module optimises data transmission efficiency. Overall, the DN-95348-2 PoE switch offers a powerful, intelligent and reliable solution for powering network components that meets today's requirements for modern network infrastructures.

Κύρια σημεία
  • Support IEEE802.3af/at Standard
  • Single port output power up to 30W
  • Automatic detection and identification of standard PoE power receiving devices, intelligent power supply, will not burn non-standard PoE power receiving devices or common devices
  • Support port power supply prioritization, guarantee the continuous power supply of key nodes
  • Panel indicators monitor working status and help fault analysis
  • Support VLAN and CCTV function
  • Flow Control for Full Duplex operation and back pressure for Half Duplex Operation
  • Support Energy-Efficient Ethernet (EEE) function (IEEE802.3az)
  • Mainboard, Power supply, PoE (three in one)
  • PoE Standard: IEEE802.3af/at
  • PoE Port: Port 1~24
  • PSE Power on RJ-45: Mode A 1/2(+),3/6(-)
  • PoE Port Output, Voltage: 55V DC, 30W max
  • PoE Power Budget: 370W
  • Power supply: 400W
  • Input Power Supply:AC 100-240V, 50/60Hz
  • Key supply: CCTV&VLAN
  • Forwarding Mode: Storage-and-Forward
  • Switching Capacity: 52 Gbps
  • MAC address table: 8K, Auto--learning, Auto-aging
  • Jumbo frames: 9216Byte
  • Packet Buffer: 4.1Mbit
  • Forwarding Rate: 38,69 Mpps
  • Operation Temperature: 0℃~40℃
  • Storage Temperature: -40℃~70℃
  • Operation Humidity: 10%~90% RH
  • Storage Humidity: 5%~90% RH
  • Dimensions(L*W*H): 440*207*44mm
  • Fan Qty:2
Χαρακτηριστικά
Full duplex
Yes
Half duplex
Yes
Jumbo frames
9216
Power over Ethernet (PoE)
Yes
Store-and-forward
Yes
Αριθμός ανεμιστήρων
2 fan(s)
Αριθμός βασικών θυρών μεταγωγής RJ-45 Ethernet
24
Αριθμός θυρών Gigabit Ethernet (χαλκού)
24
Αριθμός θυρών uplink
2
Αριθμός υποδοχών μονάδας SFP
2
Βάθος
207 mm
Βάθος συσκευασίας
500 mm
Βάρος συσκευασίας
3.57 kg
Δυνατότητα στοίβαξης
No
Ενδεικτικές λυχνίες LED
Yes
Θερμοκρασία αποθήκευσης (T-T)
-40 - 70 °C
Θερμοκρασία λειτουργίας (T-T)
0 - 40 °C
Ισχύς Power over Ethernet (PoE) ανά θύρα
30 W
Κατανάλωση ισχύος (μέγ.)
400 W
Μνήμη buffer πακέτων
4.1 MB
Μορφή (form factor)
1U
Οδηγός γρήγορης εκκίνησης
Yes
Περιλαμβάνεται τροφοδοτικό
Yes
Περιλαμβάνονται καλώδια
AC
Πηγή τροφοδοσίας
AC
Πίνακας διευθύνσεων MAC
8000 entries
Πλάτος
440 mm
Πλάτος συσκευασίας
320 mm
Πρότυπα δικτύωσης
IEEE 802.3af, IEEE 802.3at, IEEE 802.3az
Ρυθμός προώθησης
38.69 Mpps
Συνολική ισχύς Power over Ethernet (PoE)
370 W
Συχνότητα εισόδου AC
50/60 Hz
Σχετική υγρασία αποθήκευσης (H-H)
5 - 90%
Σχετική υγρασία λειτουργίας (H-H)
10 - 90%
Τάση Power over Ethernet (PoE)
55 V
Τάση εισόδου AC
100 - 240 V
Ταχύτητες δεδομένων Ethernet LAN
10,100,1000 Mbit/s
Τοποθέτηση σε rack
Yes
Τύπος switch
Unmanaged
Τύπος βασικών θυρών μεταγωγής RJ-45 Ethernet
Gigabit Ethernet (10/100/1000)
Τύπος διεπαφής Ethernet
Gigabit Ethernet
Υλικό περιβλήματος
Metal
Υποδοχή τροφοδοσίας
AC-in jack
Υποστήριξη 10G
No
Υποστήριξη jumbo frames
Yes
Υποστήριξη VLAN
Yes
Υποστήριξη αυτόματης εκμάθησης διευθύνσεων MAC
Yes
Υποστήριξη αυτόματου aging διευθύνσεων MAC
Yes
Υποστήριξη ελέγχου ροής
Yes
Ύψος
44 mm
Ύψος συσκευασίας
75 mm
Χρώμα προϊόντος
Grey
Χώρα προέλευσης
China
Χωρητικότητα μεταγωγής
52 Gbit/s
