Διακόπτης KVM DeLOCK 11481

The DeLOCK 11481 KVM switch enables control of two computers using a single HDMI monitor, one USB keyboard and one USB mouse. It supports HDMI video output up to 3840 x 2160 pixels at 60 Hz and includes two USB 2.0 ports for mouse and keyboard and two USB 3.0 ports for storage devices. The unit is built into a compact metal housing, measures 75 x 178 x 26 mm and is powered from AC 100–240 V.

Advantages

The switch consolidates video and peripheral connections, reducing cable clutter and desk equipment. It offers a high-resolution HDMI output (4K@60 Hz) for clear images and separate USB 3.0 ports for external drives. Multiple control methods are available — front-panel button, keyboard hotkey, mouse gesture or infrared remote — for flexible switching between the two connected computers.

Suitable for

• Home offices where two PCs share one monitor and keyboard/mouse
• Small offices or workstations with alternating access to two computers
• Setups requiring 4K@60 Hz HDMI output to a single display
• Users who need USB 3.0 access for external storage alongside USB input devices

Key specifications

• Model: DeLOCK 11481
• Controlled computers: 2
• Video interface: HDMI, up to 3840 x 2160 @ 60 Hz
• USB ports: 2 × USB 2.0 (keyboard/mouse), 2 × USB 3.0 (storage)
• Power: AC 100–240 V
• Housing: metal; Colour: black
• Dimensions: 75 × 178 × 26 mm
• Mouse/Keyboard interface: USB

How to use

Connect each computer's HDMI output and USB upstream cable to the corresponding input ports on the KVM switch. Attach the monitor to the HDMI output and plug the USB keyboard and mouse into the USB 2.0 ports; connect any external drives to the USB 3.0 ports. Power the device from an AC outlet. Switch the active computer via the front-panel button, assigned keyboard hotkey, mouse gesture or infrared remote control.

Recommendations

For optimal display performance, use high-quality HDMI cables rated for 4K@60 Hz and ensure connected graphics drivers support the stated resolution. When using USB 3.0 storage devices, connect directly to the USB 3.0 ports to maintain transfer speeds.
