Custom Group Custom - τροφοδοτικό - εναλλασσόμενο ρεύμα 100-240 V

Delivering clean, regulated DC output from any 100–240 V AC mains input, this switching-mode power supply achieves over 85% efficiency while maintaining ripple below 1% of output voltage. Its universal input and compact enclosed design make it a dependable core component for industrial, networking, and embedded systems.

Overview

The Custom 976DX010000002 is a high-performance AC-to-DC power supply built for continuous operation across a wide input range. It converts 50/60 Hz alternating current into stable direct current, with output voltage and current configurable to match specific load requirements. The unit employs active switching topology to minimize energy loss and heat generation, ensuring reliable performance in demanding environments.

What stands out

• Universal AC input: 100–240 V, 50/60 Hz for global compatibility
• High efficiency: typically >85%, reducing energy costs and thermal stress
• Comprehensive protection: over-voltage, over-current, and short-circuit safeguards
• Passive convection cooling for silent, maintenance-free operation
• Compact enclosed or open-frame form factor options
• CE and RoHS compliant for safety and environmental standards

Technical details

• Input voltage: 100–240 V AC
• Input frequency: 50/60 Hz
• Output type: DC (configurable voltage/current)
• Efficiency: >85% (typical, switching mode)
• Ripple & noise: <1% of output voltage
• Line regulation: ±0.5%
• Load regulation: ±1%
• Protection: OVP, OCP, SCP
• Cooling: passive convection
• Operating temperature: -10°C to 50°C
• Storage temperature: -20°C to 85°C
• Operating humidity: 20–90% RH (non-condensing)
• Input connector: IEC C14 or fixed cable (varies)
• Output connector: DC barrel jack, screw terminal, or custom
• Certifications: CE, RoHS

Our verdict

With its universal input, robust protection, and high efficiency, the Custom 976DX010000002 is a versatile power solution for integrators and OEMs. Its passive cooling and compact build simplify installation, while the wide operating temperature range ensures reliability in challenging conditions.
