Conspit H.A.O HUB Direct Drive Wheelbase 10 Nm

The Conspit H.A.O HUB is a high-performance direct drive wheelbase designed for serious sim racers. With 10 Nm of peak torque and a custom servo motor, it delivers precise, responsive force feedback for an immersive racing experience. The CNC machined aluminum alloy chassis ensures durability and rigidity, while the fanless passive cooling system keeps operation silent and reliable.

Advantages

Direct drive technology provides instant torque and smooth force feedback. The 20-bit encoder offers exceptional resolution for accurate steering input. Ultra-low latency and 1000 Hz USB polling rate ensure real-time response. Passive cooling eliminates fan noise and maintenance.

Suitable for

• Sim racing enthusiasts seeking a mid-range direct drive wheelbase
• Users who prefer a quiet, fanless operation
• Compatibility with PC (Windows) and standard sim racing mounting patterns

Key specifications

• Drive Type: Direct Drive
• Peak Torque: 10 Nm
• Motor Type: Custom Servo Motor
• Encoder Resolution: 20-bit (262144 PPR)
• USB Polling Rate: 1000 Hz
• Platform Compatibility: PC (Windows)
• Connectivity: USB-B, DC Power Input
• Chassis Material: CNC Machined Aluminum Alloy
• Mounting Options: Front Mount, Bottom Mount (Standard Sim Racing Patterns)
• Quick Release System: Conspit 70mm PCD Quick Release (included)
• Power Supply: External AC Adapter (180W)
• Input Voltage: AC 100-240V, 50/60Hz
• Output Voltage: DC 24V
• Software: Conspit SimPro Manager
• Force Feedback Technology: Advanced Force Feedback Algorithms
• Cooling System: Fanless Passive Cooling
• Latency: Ultra-low Latency
• Protection Features: Over-current, Over-voltage, Over-temperature Protection
• Included Accessories: Power Adapter, USB Cable, Mounting Screws, Quick Release
• Color: Black

Recommendations

For optimal performance, use with a compatible sim racing wheel and pedals. Ensure your PC meets the system requirements for the Conspit SimPro Manager software.
