CABLETECH Μεταλλική πρίζα κεραίας TV Μαύρο

Connecting a TV, radio, and satellite receiver to a single wall outlet can be messy and unreliable with separate sockets. This CABLETECH metal antenna socket solves that by combining all three connections into one flush-mount unit, keeping your installation neat and signal quality high.

Who is it for

Homeowners, installers, and DIY enthusiasts who need a robust, shielded wall socket for distributing TV, FM radio, and satellite signals from a single coaxial cable. Ideal for living rooms, bedrooms, or any indoor space where multiple receivers are used.

Main features

• Three outputs: TV (IEC male), Radio (IEC female), and Satellite (F-type female) for versatile connectivity.
• Wide frequency coverage: TV 5-862 MHz, Radio 87.5-108 MHz, SAT 950-2400 MHz, compatible with DVB-T/T2, DVB-S/S2, and DAB+.
• Low signal attenuation: less than 2.5 dB for TV/Radio and less than 3.0 dB for satellite, preserving signal strength.
• High shielding effectiveness (>75 dB) reduces interference from nearby electronic devices.
• Durable metal front plate with die-cast metal/plastic housing for long-lasting performance.
• Screw clamp input for secure coaxial cable connection.
• Flush-mount installation for a clean, professional look.

Specifications

• Brand: CABLETECH
• Model: 15106
• MPN: 15106
• EAN: 5901436711971
• Product type: Terminal antenna wall socket
• Signal support: TV, Radio (FM), Satellite (SAT)
• Number of outputs: 3
• TV output connector: Coaxial male (IEC male)
• Radio output connector: Coaxial female (IEC female)
• Satellite output connector: F-type female
• Frequency range TV: 5 - 862 MHz
• Frequency range Radio: 87.5 - 108 MHz
• Frequency range SAT: 950 - 2400 MHz
• Attenuation TV/Radio: < 2.5 dB
• Attenuation Satellite: < 3.0 dB
• Impedance: 75 Ohm
• Installation type: Flush-mount
• Front plate material: Metal
• Housing material: Die-cast metal / Plastic
• Colour: Black
• Shielding effectiveness: > 75 dB
• Compatibility: DVB-T/T2, DVB-S/S2, DAB+
• Input connection: Screw clamp for coaxial cable
• Application: Indoor use

Tips

For best signal quality, use high-quality coaxial cable with proper shielding and ensure the screw clamp is tightened securely. If mounting in a metal wall box, consider grounding the socket to further reduce interference.
