BVV-P Επίπεδο καλώδιο ρεύματος PVC 2x1,0 mm² Λευκό 100m

The BVV-P flat PVC power cable is designed for fixed indoor installations in dry and damp locations. With 2 cores of 1.0 mm² cross-section, it is suitable for general power distribution, lighting circuits, and control systems. The flat profile allows for discreet surface mounting or embedding in plaster.

Advantages

Space-saving flat design simplifies installation in tight spaces. PVC insulation and sheath provide good mechanical protection and resistance to moisture. Compliant with GOST standards for non-flame propagation, enhancing safety.

Suitable for

• Fixed wiring in residential and commercial buildings
• Surface-mounted or embedded installations
• Lighting and small appliance circuits
• Indoor dry and damp environments

Key specifications

• Cable type: BVV-P (Flat PVC Insulated and Sheathed)
• Number of cores: 2
• Conductor cross-section: 1.0 mm²
• Conductor material: Copper
• Insulation: PVC
• Sheath: PVC
• Outer colour: White
• Length: 100 m
• Rated voltage: 300/500 V
• Max. conductor temperature: +70°C
• Operating temperature: -50°C to +70°C
• Approx. outer dimensions: 3.5 mm x 5.5 mm
• Current carrying capacity: approx. 10 A (fixed, 2 cores in air)
• Standard: GOST 31996-2012
• Fire performance: Non-flame propagating
• RoHS compliant

Recommendations

Ensure compliance with local electrical regulations. For outdoor or direct burial applications, use a suitable outdoor-rated cable. Always consult a qualified electrician for installation.
