Busch-Jaeger SCHUKO Πρίζα Safety+ 20 EUCB-F-45M, λευκό αλπικό

Modern electrical installations demand more than just a power point—they need safety, reliability, and a clean finish. The Busch-Jaeger SCHUKO Socket Outlet Safety+ 20 EUCB-F-45M answers that call with integrated touch protection and a flush-mounted design that blends seamlessly into any room. Its screwless terminals make wiring quick and secure, while the halogen-free thermoplastic construction supports sustainable building practices.

Who is it for

This socket is ideal for electricians, contractors, and homeowners upgrading residential or commercial spaces. It suits projects requiring compliance with child-safety standards and a consistent aesthetic across multiple switch ranges, including Busch-Duro 2000® SI, Reflex SI, carat®, pure steel®, solo®, future® linear, and alpha®.

Main features

• SCHUKO socket with earthing pin and integrated Safety+ shutter for increased touch protection
• Screwless terminals for fast, tool-free installation and reduced wiring time
• Flush-mounted design for a neat, low-profile appearance
• Rated at 16 A / 250 V AC, suitable for standard European power circuits
• Alpine white (RAL 9010) glossy finish that complements most interiors
• Halogen-free thermoplastic material, contributing to low-smoke, low-toxicity installations
• IP20 protection, intended for indoor dry locations
• Compatible with a wide range of Busch-Jaeger design series for a unified look

Specifications

• Socket type: SCHUKO (CEE 7/3)
• Number of sockets: 1-gang
• Rated current: 16 A
• Rated voltage: 250 V AC
• Frequency: 50/60 Hz
• Connection type: Screwless terminals
• Mounting type: Flush mounted (Unterputz)
• Colour: Alpine white (RAL 9010)
• Material: Thermoplastic
• Degree of protection: IP20
• Halogen-free: Yes
• Surface finish: Glossy
• With hinged lid: No
• With function lighting: No
• With orientation lighting: No

Tips

For a cohesive installation, pair this socket with frames and covers from the same Busch-Jaeger design series. Always verify local wiring regulations and use appropriate cable cross-sections for 16 A circuits. The screwless terminals accept solid conductors up to 2.5 mm²; strip insulation to the recommended length for a secure connection.
