Busch-Jaeger free@home Στοιχείο χειρισμού, λευκό Άλπεων, 2-πλό 2CKA006220A0886

In a Busch-free@home smart home installation, you need a simple, elegant way to control lights, blinds, and scenes without reaching for a phone. This flush-mounted control element provides two configurable rocker points that handle switching, dimming, blind control, and scene recall directly on the wall.

Who is it for

Electricians and homeowners building or extending a Busch-free@home system who want reliable, wired control points that match the clean Busch-Jaeger design language. It requires a free@home System Access Point and a compatible cover frame (not included).

Main features

• Two configurable control points (1-gang rocker functionality)
• Supports switching, dimming, blind control, and scene recall
• Powered directly from the free@home bus (24 V DC)
• Flush-mounted design with a depth of approximately 32 mm
• Alpine White (Alpinweiß) thermoplastic housing (PC/ABS)
• IP20 protection, suitable for indoor use

Specifications

• Product type: Control element / operating element
• System: Busch-free@home
• Colour: Alpine White
• Material: Thermoplastic (PC/ABS)
• Mounting: Flush-mounted
• Number of control points: 2
• Bus system: free@home bus
• Operating voltage: 24 V DC (via bus)
• Installation depth: approx. 32 mm
• Operating temperature: -5 to +45 °C
• Relative humidity: 5 to 95 % (non-condensing)
• Configuration: via free@home System Access Point and app/web interface
• Required accessories: Busch-Jaeger cover frame (not included)
• Design line: Busch-free@home

Tips

Pair with a matching Busch-Jaeger cover frame from the free@home range for a seamless look. Use the free@home app to assign functions to each rocker point, such as dimming a group of lights or recalling a scene.
