Busch-Jaeger Flex-Set Multi BW180 σετ καθολικού ροοστάτη περιστροφής, λευκό Άλπεων 2CKA006800A3020

Adjusting light levels in a room often requires separate dimmer and switch modules, complicating installation and limiting control. The Busch-Jaeger Flex-Set Multi BW180 solves this by combining a universal rotary dimmer with a push-button on/off function in one flush-mounted unit, supporting a wide range of lamp types.

Who is it for

Electricians and homeowners who need a reliable, versatile dimming solution for incandescent, halogen, dimmable LED, and dimmable CFL lamps. Its automatic load detection and robust protection features make it suitable for both new installations and retrofits.

Main features

• Universal dimming for incandescent, HV halogen, LV halogen (electronic or conventional transformer), dimmable LED, and dimmable CFL lamps.
• Automatic load detection selects the appropriate dimming principle (leading or trailing edge).
• Rotary control for smooth dimming and push-button for on/off.
• Soft start, memory function, short-circuit, overload, and thermal protection.
• Flush-mounted design in alpine white (BW180) with screw terminals.

Specifications

• Rated voltage: 230 V AC
• Rated frequency: 50/60 Hz
• Max. power incandescent/HV halogen: 10-400 W
• Max. power LV halogen (electronic transformer): 10-400 VA
• Max. power LV halogen (conventional transformer): 10-400 VA
• Max. power dimmable LED: 3-100 W/VA
• Max. power dimmable CFL: 3-100 W/VA
• Protection class: IP20
• Connection type: screw terminals

Tips

Ensure the total connected load is within the specified range for the lamp type. For mixed loads, consult the manufacturer's guidelines. The dimmer automatically detects the load, but if flickering occurs, verify compatibility with the lamp or transformer.
