BUSCH-JAEGER BJ 20 EUKNBSL-84-101 Μονάδα πρίζας SCHUKO Studioweiß Solo 2CKA002018A1564

Installing a new power socket often means choosing between function and finish, but this SCHUKO insert keeps both in line. It delivers a standard 250 V / 16 A connection in a clean studio white, ready to be paired with your preferred cover frame.

Who is it for

Electricians and homeowners who need a reliable flush-mounted socket insert that works with standard boxes and leaves the final look to a separate cover plate.

Main features

• SCHUKO (Type F) socket, rated 250 V AC / 16 A
• Flush-mounted design for standard boxes
• Studio white thermoplastic body
• Halogen-free material
• Screw terminals for secure wiring
• Solo insert: cover frame and plate ordered separately

Specifications

• Socket type: SCHUKO (Type F)
• Rated voltage: 250 V AC
• Rated current: 16 A
• Frequency: 50/60 Hz
• Mounting: Flush-mounted
• Connection: Screw terminals
• Number of gangs: 1
• Colour: Studio white
• Material: Thermoplastic
• Degree of protection: IP20
• Halogen-free: Yes
• Child protection: No
• Minimum installation depth: 32 mm
• Suitable for: Standard flush-mounted boxes

Tips

Pair this insert with a BUSCH-JAEGER cover frame and centre plate in the same studio white finish for a complete socket. Ensure the flush-mounted box has at least 32 mm depth.
