BlueOptics 10G-SFPP-USR-E-BO Μονάδα πομποδέκτη δικτύου Οπτική ίνα 10000 Mbit/s SFP+

The BlueOptics 10G-SFPP-USR-E-BO is an SFP+ fiber optic transceiver module designed for 10 Gigabit Ethernet and similar high-speed optical applications. It supports a maximum data rate of 10,000 Mbit/s over multimode fiber using an LC duplex connector and complies with industry certifications such as RoHS, CE and FCC. The module is compact and lightweight, making it suitable for installation in switches, routers and storage systems that accept SFP+ modules and follow MSA specifications.

Advantages

The module implements 10GBASE-SR optical signaling with 850 nm transmitter and receiver wavelengths, enabling short-range high-bandwidth links up to the specified multimode distance. Full MSA compliance ensures mechanical and electrical interoperability with compatible hardware. Built-in digital diagnostics (DDM/DOM) provides real-time monitoring of supply voltage, laser bias current, transmit power, receive power and temperature to assist with maintenance and troubleshooting. The transceiver is manufactured to industrial quality standards and meets CE, RoHS and FCC requirements.

Suitable for

• 10 Gigabit Ethernet connections over multimode fiber
• High-speed links between switches, routers and servers
• Storage area network (SAN) and Fibre Channel over Ethernet (FCoE) links
• Short-reach campus and data center interconnects (LC duplex)

Key specifications

• Interface type: SFP+
• Maximum data transfer rate: 10,000 Mbit/s (10G)
• Optical wavelength: 850 nm (TX and RX)
• Connector: LC duplex
• Fiber type: multimode fiber (MMF), short-range application
• Digital diagnostics: DDM/DOM (MSA SFF-8472 compliant)
• Certifications: RoHS, CE, FCC
• Product colour: Chrome
• Weight: 0.02 kg

How to use

Install the BlueOptics SFP+ transceiver into an SFP+ slot on a compatible switch, router or server until it clicks into place. Use a compatible LC duplex multimode fiber patch cable between transceivers or to a patch panel. Ensure the host device supports third-party SFP+ modules and, if required, enable or verify DDM/DOM support in the system to access real-time diagnostic data. Observe standard electrostatic discharge (ESD) precautions when handling the module and avoid touching the optical interfaces; keep protective caps on when not connected.

Recommendations

For optimal performance, match the transceiver to appropriate multimode fiber (OM3/OM4 where applicable) and keep link lengths within the module's supported range. Verify compatibility with the specific hardware platform and firmware version before deployment, and use digital diagnostics to monitor link health and schedule maintenance as needed.
