BlueOptics 10G-SFPP-TWX-P-0301-BL καλώδιο SFP+ Direct Attach Copper 3m - Aqua

The BlueOptics 10G-SFPP-TWX-P-0301-BL is a high-performance 3-meter SFP+ Direct Attach Copper (DAC) cable designed for 10 Gigabit Ethernet, InfiniBand, and Fibre Channel applications. This passive twinax copper cable features an aqua-colored jacket and is hot-swappable, providing reliable connectivity for data centers, server-to-switch links, and storage area networks.

Advantages

This DAC cable offers a cost-effective and low-power solution for short-range high-speed connections. With a data rate of 10 Gbps and impedance of 100 Ohm, it ensures signal integrity and minimal latency. The passive design consumes less than 0.5W, making it energy-efficient. It is multi-vendor compatible and complies with RoHS, CE, FCC, and MSA standards.

Suitable for

• Data center interconnect
• Server-to-switch connections
• Storage area networks (SAN)
• InfiniBand clusters
• 10 Gigabit Ethernet networks

Key specifications

• Product Type: Direct Attach Copper (DAC) Cable
• Data Rate: 10 Gbps
• Connector Type: SFP+ to SFP+
• Cable Length: 3 meters
• Cable Color: Aqua
• Cable Material: Twinax Copper
• Cable Gauge: 30 AWG
• Passive/Active: Passive
• Impedance: 100 Ohm
• Jacket Material: PVC
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C
• Compliance: RoHS, CE, FCC, MSA Compliant
• Power Consumption: < 0.5W
• Hot-Swappable: Yes

Recommendations

For optimal performance, ensure that both ends of the cable are connected to compatible SFP+ ports. This cable is ideal for short-distance, high-speed data transmission within racks or between adjacent racks.
