Biamp SPA-GSQ100

The Biamp SPA-GSQ100 is a professional 4-channel power amplifier delivering 100W per channel into 4Ω or 8Ω loads, or 100W per channel at 70V/100V for high-impedance distributed audio systems. Its Class D topology ensures high efficiency and low heat dissipation, enabling fanless convection cooling for silent operation in noise-sensitive environments. The amplifier integrates seamlessly with TesiraFORTÉ X DSP systems via Ethernet, providing remote control and monitoring. With a total output of 400W in a compact 1RU chassis, it is ideal for corporate AV, education, hospitality, and performance venues requiring reliable, high-quality audio amplification.

Advantages

The SPA-GSQ100 offers exceptional audio fidelity with a frequency response of 20 Hz to 20 kHz (±0/-1.5 dB) and THD+N below 0.1% across the full power range. Its high signal-to-noise ratio (>100 dB A-weighted) ensures a clean, noise-free signal path. Fanless convection cooling eliminates mechanical noise, making it suitable for boardrooms, theaters, and recording studios. The amplifier supports both low-impedance (4Ω/8Ω) and high-impedance (70V/100V) outputs, providing flexibility for a wide range of speaker configurations. Comprehensive protection circuitry guards against over-current, over-temperature, DC offset, and short circuits, ensuring long-term reliability. Integration with TesiraFORTÉ X allows advanced DSP control, including level, mute, and fault monitoring over the network.

Suitable for

• Corporate boardrooms and conference rooms requiring silent operation
• Educational institutions for classrooms, lecture halls, and auditoriums
• Hospitality venues such as restaurants, hotels, and bars with background music
• Performance spaces and houses of worship needing flexible multi-zone amplification
• Any TesiraFORTÉ X-based AV system requiring reliable, remotely managed amplification

Key specifications

• 4 channels, 100W per channel @ 4Ω/8Ω or 70V/100V
• Total output power: 400W
• Class D amplifier topology with fanless convection cooling
• Frequency response: 20 Hz – 20 kHz (+0/-1.5 dB)
• THD+N: < 0.1% (20 Hz – 20 kHz, 1W to rated power)
• Signal-to-noise ratio: > 100 dB (A-weighted)
• Inputs: 4x balanced Phoenix connectors (3.81 mm)
• Outputs: 4x Phoenix connectors (5.08 mm)
• Input sensitivity: 0 dBu (0.775 Vrms); Input impedance: 10 kΩ balanced
• Network control: 1x RJ-45 Ethernet for Tesira system integration
• Universal power supply: 100–240 VAC, 50/60 Hz
• Protection: over-current, over-temperature, DC offset, short circuit
• Certifications: CE, FCC, UL, RoHS, ENERGY STAR
• Rack space: 1RU

Recommendations

For installations demanding pristine audio quality, silent operation, and flexible output configurations, the Biamp SPA-GSQ100 is a top-tier choice. Pair it with TesiraFORTÉ X processors to unlock full remote management and DSP capabilities, ensuring a streamlined and reliable audio distribution system for any professional environment.
