BCS BCS-P-LSIPI15 2K CMOS γραμμική κάμερα, 20 kHz, C-Mount, μονόχρωμη

The BCS BCS-P-LSIPI15 is a high-performance 2K CMOS line scan camera designed for industrial machine vision applications. With a resolution of 2048 pixels and a maximum line rate of 20 kHz, it delivers fast and accurate image capture for demanding inspection tasks. The camera features a compact aluminum housing, C-Mount lens compatibility, and a PiP (Parallel-in-Parallel-out) interface for seamless integration.

Advantages

High-speed line rate of 20,000 lines per second enables rapid inspection of moving objects. Selectable 8-bit or 10-bit output provides flexibility between speed and image quality. Programmable exposure and gain control allow optimization for various lighting conditions. Robust aluminum housing ensures durability in industrial environments.

Suitable for

• Industrial quality inspection and sorting
• Printing and packaging inspection
• Web inspection (textile, paper, film)
• Food and beverage inspection
• Electronics manufacturing

Key specifications

• Sensor: CMOS, 2048 pixels (2K)
• Pixel Size: 10 µm x 10 µm
• Max Line Rate: 20 kHz
• Interface: PiP (Parallel-in-Parallel-out)
• Bit Depth: 8-bit / 10-bit selectable
• Spectral Range: Visible (400-700 nm)
• Lens Mount: C-Mount
• Power Supply: 12V DC
• Exposure Control: Programmable
• Gain Control: Programmable
• Trigger Modes: External, Free-run
• Output Data Format: Monochrome
• Operating Temperature: 0°C to +50°C
• Housing Material: Aluminum

Recommendations

For optimal performance, use with a compatible frame grabber or interface card. Ensure proper lens selection for your application's field of view and resolution requirements. The camera is designed for indoor use; protect from moisture and extreme temperatures.
