ASRock H810M-P Gen5 μητρική, LGA 1851, Micro-ATX, DDR5

The ASRock H810M-P Gen5 is a Micro-ATX motherboard built on the Intel H810 chipset with an LGA 1851 socket, supporting Intel Core Ultra (Series 2) processors. It offers dual-channel DDR5 memory across two DIMM slots, a PCIe 5.0 x16 slot, and multiple M.2 and SATA III storage options.

Key features

• Supports Intel Core Ultra (Series 2) processors on LGA 1851
• Intel H810 chipset in Micro-ATX form factor
• Dual-channel DDR5 memory, up to 128 GB across 2 DIMM slots
• PCIe 5.0 x16 slot for next-generation graphics cards
• Dual M.2 slots: one Hyper M.2 PCIe Gen4x4 (64 Gb/s) and one Key E slot for WiFi/BT modules
• 4 x SATA3 6.0 Gb/s connectors
• HDMI 2.1 and DisplayPort 1.4 outputs with HDCP 2.3
• 7.1 CH HD Audio via Realtek ALC897 codec
• Gigabit LAN via Realtek RTL8111H controller

Specifications

• Brand: Asrock
• Model: H810M-P Gen5
• MPN: 90-MXBUE0-A0UAYZ
• Socket: LGA 1851
• Chipset: Intel H810
• Form factor: Micro-ATX
• Memory type: DDR5-SDRAM
• Memory slots: 2 x DIMM
• Maximum internal memory: 128 GB
• Memory channels: Dual-channel
• Supported memory clock speed (max): 6400 MHz
• Unbuffered memory: Yes
• ECC compatibility: Non-ECC
• Storage drive types: HDD & SSD
• Supported storage drive interfaces: M.2, SATA III
• Number of storage drives supported: 5
• Number of HDDs supported: 4
• Number of SATA III connectors: 4
• Number of M.2 (M) slots: 1
• PCI Express x16 (Gen 5.x) slots: 1
• PCI Express x1 (Gen 4.x) slots: 1
• USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
• USB 2.0 connectors: 2
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
• USB 2.0 ports quantity: 4
• HDMI ports quantity: 1
• HDMI version: 2.1
• DisplayPorts quantity: 1
• DisplayPort version: 1.4
• Ethernet LAN (RJ-45) ports: 1
• Ethernet LAN: Yes
• Ethernet interface type: Gigabit Ethernet
• LAN controller: Realtek RTL8111H
• Audio output channels: 7.1 channels
• Audio chip: Realtek ALC897
• HDCP: Yes
• HDCP version: 2.3
• Maximum resolution: 7680 x 4320 pixels
• BIOS type: UEFI AMI
• Power source type: ATX
• Windows operating systems supported: Windows 11 x64
• Width: 244 mm
• Depth: 193 mm
