APC ZBZ33 τυφλό πώμα για Harmony XB4/XB5 - μαύρο - 10 τεμ.

The APC ZBZ33 is a high-quality blanking plug designed for use with Schneider Electric Harmony XB4 and XB5 series. This pack of 10 black plastic plugs provides a clean and professional finish for unused panel openings, ensuring protection against dust, moisture, and mechanical impact. Ideal for industrial control panels, these plugs offer robust sealing with IP65, IP67, IP69, and IP69K ratings, as well as NEMA 13 and 4X protection. They are suitable for a wide operating temperature range of -40 to 70 °C and comply with international standards including EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508, and CSA C22.2 No 14. The plugs are RoHS and REACH compliant, mercury-free, and resistant to vibration (5 gn) and shock (30 gn).

Advantages

These blanking plugs ensure reliable sealing and durability in harsh environments. Their easy snap-in installation saves time, and the black color blends seamlessly with most panels. The high protection ratings make them suitable for food processing, chemical plants, and outdoor applications.

Suitable for

• Industrial control panels
• Automation systems
• Electrical enclosures
• Machinery and equipment

Key specifications

• Product Type: Blanking Plug
• Series Compatibility: Harmony XB4, Harmony XB5
• Hole Diameter: 22 mm
• Color: Black
• Material: Plastic
• Quantity per Pack: 10 pieces
• Head Diameter: 29.5 mm
• Overall Depth: 13 mm
• Panel Cut-out Diameter: 22.5 mm
• IP Protection Rating: IP65, IP67, IP69, IP69K
• NEMA Protection Rating: NEMA 13, NEMA 4X
• Operating Temperature: -40 to 70 °C
• Storage Temperature: -40 to 70 °C
• Standards: EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508, CSA C22.2 No 14
• RoHS Status: Compliant
• REACH Status: Compliant
• Mercury Free: Yes
• Vibration Resistance: 5 gn (2-500 Hz) conforming to IEC 60068-2-6
• Shock Resistance: 30 gn (18 ms half-sine wave acceleration) conforming to IEC 60068-2-27

Recommendations

For optimal performance, ensure the panel cut-out is clean and free of debris before installation. These plugs are designed for a secure fit and should not be used in applications requiring electrical conductivity.
