Αναγνώστης ελέγχου πρόσβασης Avigilon OP-R2X-MULL μαύρο 12-24V 45 mm 22 mm 120 mm

The Avigilon Mullion Smart Reader v2 is a compact, surface-mount access control reader designed for secure entry where mounting space is limited. The black OP-R2X-MULL model supports an input voltage of 12–24 V and measures 45 mm wide, 22 mm deep and 120 mm high, combining a slim profile with industry-grade security for reliable access control applications.

Advantages

The reader's slim mullion form factor allows installation on narrow door frames and mullions without occupying significant space. Its black finish provides a low-profile appearance suitable for many environments. Operating on 12–24 V input voltage, the device integrates easily with common access control power supplies and systems while delivering consistent credential reading performance.

Suitable for

• Surface mounting on narrow door frames or mullions
• Access control points with limited mounting space
• Commercial and institutional entryways requiring discrete hardware

Key specifications

• Model: OP-R2X-MULL
• Brand: Avigilon
• Color: Black
• Input voltage: 12–24 V
• Dimensions (W×D×H): 45 mm × 22 mm × 120 mm
• EAN: 5715063740910

How to use

Mount the reader on a flat mullion or narrow frame using appropriate screws and anchors for the surface material. Connect the reader to the access control panel or controller following the manufacturer's wiring diagram and supply 12–24 V DC power. Enroll credentials through the access control system and verify read range and operation before finalizing installation.

Recommendations

Install the reader at a convenient height for users and away from direct weather exposure when possible. Follow Avigilon's installation and wiring guidelines to ensure reliable operation and compliance with system requirements.
