ALLNET ALL-BRICK-0041 25V N-Channel MOSFET Transistor DPAK

The ALLNET ALL-BRICK-0041 is a high-performance N-Channel Enhancement Mode MOSFET in a DPAK (TO-252) surface-mount package. Designed for efficient power switching and regulation, this transistor delivers a continuous drain current of 20 A with a low on-resistance of 10 mΩ, making it ideal for DC-DC converters, motor control, and power management applications.

Advantages

Low on-resistance (Rds(on) = 10 mΩ) minimizes conduction losses and improves efficiency. Fast switching speeds with typical turn-on delay of 10 ns and turn-off delay of 20 ns enable high-frequency operation. RoHS and Halogen Free compliant, ensuring environmental safety.

Suitable for

• Power supply circuits
• DC-DC converters
• Motor control drivers
• Battery management systems
• Load switching

Key specifications

• Transistor Type: N-Channel MOSFET
• Drain-Source Voltage (Vds): 25 V
• Continuous Drain Current (Id): 20 A (at 25°C)
• On-Resistance (Rds(on)): 10 mΩ (at Vgs=10V, Id=10A)
• Gate-Source Voltage (Vgs): ±20 V
• Gate Threshold Voltage (Vgs(th)): 2 V (typical)
• Power Dissipation (Pd): 30 W (at 25°C)
• Package Type: DPAK (TO-252)
• Mounting Type: Surface Mount
• Operating Temperature Range: -55°C to +150°C
• Number of Pins: 3
• Channel Mode: Enhancement Mode
• Input Capacitance (Ciss): 1000 pF (typical)
• Output Capacitance (Coss): 200 pF (typical)
• Reverse Transfer Capacitance (Crss): 50 pF (typical)
• Turn-On Delay Time (td(on)): 10 ns (typical)
• Turn-Off Delay Time (td(off)): 20 ns (typical)
• Body Diode Forward Voltage (Vsd): 1.2 V (typical)
• RoHS Compliant: Yes
• Halogen Free: Yes

Recommendations

For optimal thermal performance, ensure adequate PCB copper area and consider heatsinking if operating near maximum power dissipation. Suitable for automated SMT assembly processes.
