ALLNET ALL-BRICK-0003 Μονάδα τρανζίστορ IGBT 600V 50A μονάδα ισχύος

The ALLNET ALL-BRICK-0003 is a high-performance IGBT (Insulated Gate Bipolar Transistor) power module designed for demanding industrial applications. With a maximum collector-emitter voltage of 600V and continuous collector current of 50A, this single transistor module delivers reliable switching and power handling in motor control, power supplies, inverters, and automation systems. The module features a fast recovery diode, low saturation voltage (2.0V typ.), and a typical switching frequency up to 20 kHz, making it ideal for efficient power conversion.

Advantages

Robust screw-mount power module with 2500Vrms isolation voltage ensures safe operation in high-voltage environments. Wide operating temperature range (-40°C to +150°C) and high power dissipation (200W) provide durability and long service life. Integrated fast recovery diode reduces switching losses and improves efficiency.

Suitable for

• Motor control and drives
• Switching power supplies
• Inverters and converters
• Industrial automation equipment
• Renewable energy systems

Key specifications

• Transistor Type: IGBT
• Configuration: Single Transistor Module
• Max Collector-Emitter Voltage (Vce): 600 V
• Max Continuous Collector Current (Ic): 50 A
• Max Gate-Emitter Voltage (Vge): ±20 V
• Max Power Dissipation (Pd): 200 W
• Operating Temperature Range: -40°C to +150°C
• Package Type: Power Module
• Isolation Voltage: 2500 Vrms
• Mounting Type: Screw Mount
• Typical Switching Frequency: Up to 20 kHz
• Collector-Emitter Saturation Voltage (Vce(sat)): 2.0 V (typ. @ 50A)
• Gate Charge (Qg): 150 nC (typ.)
• Integrated Diode Type: Fast Recovery Diode

Recommendations

For optimal performance, ensure proper heatsinking and follow the manufacturer's mounting torque specifications. Suitable for use in three-phase inverters and motor drives where high efficiency and reliability are required.
