RUBI Diamond Blade CEV 250 SUPERPRO 250 mm

The RUBI Diamond Blade CEV 250 SUPERPRO is a professional-grade continuous rim diamond blade designed for wet cutting of hard ceramic materials. With a diameter of 250 mm and a bore of 25.4 mm, this blade delivers precise, clean cuts in ceramic tiles, porcelain stoneware, glazed stoneware, rustic stoneware, and extruded stoneware. The sintered diamond segments ensure long life and consistent performance, making it an essential tool for professional tilers and contractors.

Advantages

Continuous rim design provides smooth, chip-free cuts. Sintered diamond bonding offers superior durability and cutting speed. Suitable for wet cutting, reducing dust and heat buildup. Compatible with standard 1-inch arbor machines.

Suitable for

• Ceramic tiles
• Porcelain stoneware
• Glazed stoneware
• Rustic stoneware
• Extruded stoneware

Key specifications

• Blade Type: Continuous Rim
• Cutting Method: Wet Cutting
• Blade Diameter: 250 mm
• Bore Diameter: 25.4 mm (1 inch)
• Rim Height: 7 mm
• Rim Thickness: 1.6 mm
• Max RPM: 6100 RPM
• Quality Level: SUPERPRO (Professional)
• Blade Material: Diamond Segmented Steel Core
• Segment Bonding: Sintered

Recommendations

Always use water for cooling during cutting to extend blade life and ensure optimal performance. Ensure the blade is mounted correctly and the machine's RPM does not exceed the maximum rated speed.
