LANVIEW 19 inch 7U IP66 Επιτοιχια θηκη – Γκρι (RAL 7035)

IP66-rated protection meets rugged steel construction in this LANVIEW 19" 7U wall mount enclosure. Engineered to shrug off dust, rain, and high-pressure water jets, it keeps switches, patch panels, and small servers safe in outdoor or washdown environments. The powder-coated grey finish (RAL 7035) resists corrosion while maintaining a clean, professional look.

Overview

This 7U wall-mount cabinet is built for demanding installations where standard racks fall short. The IP66 rating means it is completely dust-tight and protected against powerful water jets, making it suitable for industrial floors, outdoor cabinets, and areas requiring frequent cleaning. The 19-inch rack width ensures universal compatibility with standard equipment, while the fixed side and rear panels add structural rigidity and simplify sealing.

What stands out

• IP66 ingress protection: Fully protected against dust and high-pressure water, suitable for outdoor or washdown areas.
• Robust steel build: Powder-coated grey (RAL 7035) for corrosion resistance and a clean, professional look.
• 3-point locking system: Secure front door with a reliable locking mechanism to deter tampering.
• Flexible cable entry: Flange plates at top and bottom allow clean, adjustable cable routing while maintaining the seal.
• Integrated grounding: Grounding bolt included for safe electrical bonding.

Technical details

• Rack units: 7U
• Rack width: 19 inch
• External dimensions (W x D x H): 600 x 600 x 390 mm
• Usable depth: approx. 500 mm
• Material: Steel
• Surface finish: Powder-coated
• Colour: Grey (RAL 7035)
• Door: Single front steel door, opens 120°
• Side panels: Fixed (welded)
• Rear panel: Fixed (welded)
• Locking system: 3-point locking
• Cable entry: Flange plates (top and bottom)
• Grounding: Grounding bolt included
• Static load capacity: 100 kg
• Standards compliance: IEC 60529, EN 60529

Our verdict

A dependable, weatherproof enclosure that delivers serious protection for network hardware in harsh environments. The IP66 rating, solid steel build, and secure locking make it a top choice for outdoor or industrial deployments.
