HPE ANW 9106 (RW) Hybrid Gate-Stock

The HPE ANW 9106 (RW) Hybrid Gate-Stock is a high-performance isolated half-bridge gate driver designed for demanding industrial applications. It provides robust drive capability with 6 A source and 8 A sink peak output currents, ensuring efficient switching of power transistors. With reinforced isolation of 3750 Vrms and advanced protection features, this module delivers reliable operation in motor drives, inverters, and power systems.

Advantages

Reinforced isolation ensures safety and noise immunity. Integrated desaturation detection and active Miller clamp enhance system reliability. Wide supply voltage range (15 V to 30 V) offers flexibility. High common mode transient immunity (>50 kV/µs) prevents false triggering.

Suitable for

• Motor drives and industrial inverters
• UPS and solar inverter systems
• Switching power supplies

Key specifications

• Driver Type: Isolated Half-Bridge Gate Driver
• Number of Channels: 2
• Peak Output Current (Source): 6 A
• Peak Output Current (Sink): 8 A
• Supply Voltage (VCC): 15 V to 30 V
• Logic Input Voltage Compatibility: 3.3 V / 5 V CMOS/TTL
• Isolation Voltage: 3750 Vrms (Reinforced)
• Propagation Delay (Max): 150 ns
• Output Rise Time (Typ): 25 ns
• Output Fall Time (Typ): 20 ns
• Operating Temperature Range: -40°C to +125°C
• Package Type: 16-pin SIP Module
• Protection Features: Under-Voltage Lockout (UVLO), Desaturation Detection, Active Miller Clamp
• Common Mode Transient Immunity (CMTI): >50 kV/µs
• Maximum Switching Frequency: 200 kHz
• Mounting Type: Through-hole
• Power Dissipation (Max): 2 W

Recommendations

For optimal performance, ensure proper thermal management and follow the recommended layout guidelines. This gate driver is ideal for new designs requiring high reliability and isolation.
