EFB Simplex καλώδιο patch SC/APC-SC/APC OS2 G657A2 5m LSZH 3mm κίτρινο

This EFB Elektronik fiber optic patch cable is designed for high-performance single-mode networks. With SC/APC connectors on both ends, it ensures low insertion loss and high return loss, making it ideal for FTTH, CATV, and telecommunication applications. The bend-insensitive G.657.A2 fiber allows for tight bends without signal degradation, while the LSZH jacket provides safety in enclosed spaces.

Advantages

Low insertion loss (≤0.25 dB) and high return loss (≥60 dB) ensure reliable signal transmission. The bend-insensitive fiber simplifies installation in tight spaces. LSZH jacket reduces toxic smoke in case of fire.

Suitable for

• FTTH (Fiber to the Home) installations
• CATV networks
• Telecommunication infrastructure
• Data centers requiring single-mode connections

Key specifications

• Connector type: SC/APC to SC/APC
• Fiber mode: Single-mode (OS2)
• Fiber class: G.657.A2 (bend-insensitive)
• Cable length: 5 meters
• Core/Cladding: 9/125 µm
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Jacket color: Yellow
• Insertion loss: ≤0.25 dB
• Return loss: ≥60 dB
• Operating temperature: -20°C to 70°C

Recommendations

For optimal performance, ensure connectors are clean before mating. Avoid excessive bending beyond the minimum bend radius. This cable is compatible with standard SC/APC ports.
