EFB Electronics Network Coupler LC/APC Single Mode Simplex λευκό

The EFB Electronics Network Coupler LC/APC Single Mode Simplex White is a high-performance fiber optic adapter designed for reliable single-mode connections. Featuring LC/APC connectors on both sides, this coupler ensures low insertion loss and high return loss, making it ideal for demanding network environments.

Advantages

This coupler offers exceptional signal integrity with insertion loss ≤0.2 dB and return loss ≥60 dB. The zirconia ceramic ferrule provides durability and precise alignment, while the plastic housing in white ensures easy identification. With a mating durability of over 500 cycles, it is built for long-term use.

Suitable for

• Fiber optic network installations requiring single-mode connections
• Telecommunications and data center applications
• FTTx and CATV systems
• Testing and measurement setups

Key specifications

• Connector Type: LC/APC to LC/APC
• Fiber Mode: Single Mode (OS1/OS2)
• Adapter Type: Simplex
• Ferrule Material: Zirconia Ceramic
• Housing Material: Plastic
• Housing Color: White
• Ferrule Color: Green (APC standard)
• Insertion Loss: ≤ 0.2 dB
• Return Loss: ≥ 60 dB
• Mating Durability: > 500 cycles
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Mounting Type: Flange Mount
• Compliance: RoHS, REACH
• Wavelength Range: 1260 nm - 1620 nm

Recommendations

For optimal performance, use with LC/APC patch cables and ensure clean connector ends before mating. This coupler is compatible with standard single-mode fiber systems.
