EFB Electronics Καλώδιο patch - MT-RJ Multimode (M) 2m OM2 LSZH Πορτοκαλί

The EFB Electronics O0721.5 patch cable is a high-performance fiber optic solution designed for reliable data transmission in LAN, SAN, and data center environments. Featuring MT-RJ male connectors on both ends, this duplex multimode cable supports OM2 performance with 50/125 µm core/cladding diameter, ensuring efficient connectivity for 1 Gbps and 10 Gbps networks.

Advantages

This cable offers low insertion loss (<0.5 dB) and high return loss (>20 dB), minimizing signal degradation. The LSZH (Low Smoke Zero Halogen) jacket enhances safety in confined spaces, while the durable construction ensures long-term reliability.

Suitable for

• Data center patching and cross-connects
• Local area network (LAN) backbone connections
• Storage area network (SAN) links
• Telecommunications and enterprise cabling

Key specifications

• Cable Type: Fiber Optic Patch Cable
• Connector A: MT-RJ Male
• Connector B: MT-RJ Male
• Fiber Type: Multimode
• Fiber Class: OM2
• Core/Cladding Diameter: 50/125 µm
• Cable Configuration: Duplex
• Cable Length: 2 m
• Jacket Color: Orange
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Insertion Loss (typical): < 0.5 dB
• Return Loss (typical): > 20 dB
• Attenuation @ 850nm: 3.0 dB/km
• Attenuation @ 1300nm: 1.0 dB/km
• Bandwidth @ 850nm: 500 MHz*km
• Bandwidth @ 1300nm: 500 MHz*km
• Operating Temperature: -20°C to 70°C
• Storage Temperature: -40°C to 85°C
• Standards Compliance: IEC 61754-18, TIA/EIA-604-12

Recommendations

For optimal performance, pair this cable with compatible MT-RJ transceivers and patch panels. Ensure proper handling and storage within specified temperature ranges.
